Deepcool PN750M 750W 80 Plus Gold Modular Power Supply
Deepcool PN750M 750W 80 Plus Gold Modular Power Supply
Regular price
Rs. 6,800.00
Regular price
Rs. 7,999.00
Sale price
Rs. 6,800.00
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
DeepCool PM750M Series non-modular power supplies are certified 80 PLUS Gold for efficient power delivery with great performance at a great value.
80 PLUS GOLD CERTIFIED
Guarantees a minimum efficiency of 90% or higher under typical loads for reliable power delivery with little waste.
QUALITY TOPOLOGY
For solid power performance and minimal signal noise, the PM-M series PSU features a full-bridge LLC topology with DC-DC conversion and Japanese bulk capacitors that delivers terrific reliability.
BUILT TO SPEC
Made to meet modern power supply design standards for consistent voltage stability, each PM-M power supply is also compliant with Intel PSU guidelines that support instant-on power from sleep or standby modes.
EFFICIENCY THROUGHOUT
The PM-M series power supplies are compliant with the 2014 ErP regulations on energy savings and also the IEC 62368-1 for safety standards.
| Type | ATX12V V3.1 |
| 80PLUS Certifications | GOLD |
| Fan Size | 120mm |
| Fan Bearing | Hypro Bearing |
| Topology | Active PFC + Full Bridge SRC LLC + DC to DC |
| Capacitors | Japanese Bulk Capacitor |
| Power Good Signal | 100-500ms |
| Hold Up Time | ≥16ms(75% Load) |
| Efficiency | ≥90% Under Typical Load(50% Loading) |
| Protection | OPP/OVP/SCP/OTP/OCP/UVP |
| Operation Temperature | 0-40°C |
| Connectors |
Main Power Connector (20+4)Pin x 1
CPU(4+4)Pin x 1
PCI-E(6+2)Pin x 1 SATA x 3 4Pin Peripheral x 3 |
| Regulatory | TUV/cTUVus/CCC/CE/FCC/UKCA/EAC/BIS/RCM/CAN ICES-003(B)/NMB-003(B) |
| MTBF | 100,000 Hours |
| Product Dimensions | 150×140×86mm (W x L x H) |
| Warranty | 10 Year Warranty |
